9m RSJ Poles

Number of Cores 12core Size (Cross-Sectional Area) 2.5 sq.mm Conductor Size 2.5sqmm Insulation Material both xlpe and pvc Application Control Cable Cable Length 500 meter Brand Polycab Voltage 450/750 V Current Rating 16–17A Availability In Stock The 12-core, 2.5 sq mm copper armoured multistrand control cable is designed for industrial control and instrumentation applications. It consists of 12 high-conductivity stranded copper conductors, each with a cross-sectional area of 2.5 sq mm, insulated with XLPE (Cross-Linked Polyethylene) for excellent thermal and electrical performance. The insulated cores are covered with a PVC inner sheath, and the cable is protected by galvanised steel wire or strip armouring, depending on the variant, to provide mechanical strength. A durable PVC outer sheath ensures resistance to moisture, abrasion, and chemicals. The cable is rated for 650/1100 V, supports continuous operation at 90 °C, and can withstand short-circuit temperatures up to 250 °C. It conforms to IS 7098-1, IS 8130, and IS 3975 standards. This cable is suitable for control panels, industrial automation, machinery wiring, and low-voltage control circuits, providing reliable performance in harsh industrial environments. It is supplied and distributed by Laxmi Trading Services, offering dependable availability and support for industrial and commercial projects.

Number of Cores 2 Core Size (Cross-Sectional Area) 2.5 sq.mm Conductor Size 2.5sqmm Application Control Cable Cable Length 500 meter Brand Polycab Voltage 1100 V Packaging Type Roll Insulation Material both xlpe and pvc Parameter Typical Specification Number of Cores (C) 2 cores Conductor Cross‑Sectional Area 2.5 sq mm per core Conductor Material Copper (multistranded) Class of Conductor (Stranding) Multistranded (flexible) Insulation Material PVC (some may use XLPE) Voltage Rating Typically up to 1100 V for many armoured control/power cables. Armouring Galvanised steel wire in many designs Outer Sheath PVC outer sheath in common cables Operating Temperature ~ 70°C for some PVC‑insulated armoured types. DC Resistance (Conductor) Example: Epsillon lists max DC resistance ~13.7 ohm/km for their 2 C x 2.5 sq mm. Armour Wire Size Depends on cable diameter: e.g., for certain sizes, use 1.4 mm GS wire. Standards / Specification Compliance Commonly made to IS:1554‑Part 1 (control / armoured cables) according to some manufacturers. Core Identification (Colour) For 2-core control cable: typically red and black as per IS‑1554.

Power 25 kVa Input Voltage 240V Phase Single Phase Frequency 50Hz IP Rating IP65 Incepted in the year 2020 Laxmi Treding Services is distinguished Wholesaler And Service Provider Offering an Enormous Consignment Of Electrical Transformer,Suspension Clamp,Flood Light,VCE Panel,VCB Panel,Earthing Electrode,Feeder Pillar Etc .
