System Voltage 11 kV CT Ratio 25/5 A Phase Three Phase Rated Voltage 11 KV Type Dry Type CT/PT Type both dry/oil Material MS Ingress Protection (IP) Rating IP54 Material of Construction Mild Steel (MS) Certifications MSEDCL Approved, CPRI Approved Compartments Dual Compartment Use To Monitor And Measure Electricity Consumption In Industrial And Domestic Settings Surface Finish Powder Coated Metering cubicle, CTs (Current Transformers) and PTs (Potential / Voltage Transformers) must meet relevant Indian Standards: e.g., CTs per IS 2705, PTs per IS 3156. According to Maharashtra DISCOM (MSEDCL) technical spec, the 11 kV metering cubicle should have 3 CTs + 3 PTs. Environmental and site conditions: design needs to account for temperature (max ambient ~50°C in certain specs), humidity, rain, seismic loads, etc.Insulation and withstand voltages: The design involves adequate insulation strength and creepage / clearance distances for 11 kV systems. For example, SASA Switchgears specifies lightning impulse withstand voltage, power frequency withstand, etc Incepted in the year 2020 Laxmi Treding Services is distinguished Wholesaler And Service Provider Offering an Enormous Consignment Of Electrical Transformer,Suspension Clamp,Flood Light,VCE Panel,VCB Panel,Earthing Electrode,Feeder Pillar Etc . Additional Information: Production Capacity: CT -100–800 A primary, 5 A secondary PT -11 kV primary, 110 V secondary (for metering) Delivery Time: ready stock Packaging Details: as per customer requirement

System Voltage 11 kV CT Ratio 25/5 A Installation Type Outdoor CT/PT Type Dry Type/Resin Cast Ingress Protection (IP) Rating IP54 Material of Construction Mild Steel (MS) Certifications MSEDCL Approved Compartments Single Compartment Technical Details / Specifications1. Standards & Reference Specs Often designed per IS standards (e.g., IS-2705 for CT/PT) and sometimes relevant IEC standards. Example: Maharashtra DISCOM spec for 11 kV cubicles. Environmental design: the spec may consider relative humidity, rainfall, seismic, etc. 2. Mechanical / Enclosure Construction Compartmentalization: The cubicle typically has four compartments: CT / PT compartment Meter compartment Incoming cable compartment Outgoing cable compartment Metal enclosure: Usually fabricated from mild steel / cold-rolled sheet. Example: BSES spec: 2 mm sheet for general panel, 3 mm for HV compartment. Protection / IP rating: For outdoor type, IP54 is a typical minimum for the enclosure. Doors / Access: Meter compartment: glass window in door for meter reading. Interlocks: e.g., CT/PT compartment top cover interlocked so it cannot be opened unless meter compartment is opened. Concealed hinges, pad-locking, sealing arrangements for security / anti-theft. 3. Instrument Transformers (CT / PT) CTs (Current Transformers): Resin-cast (epoxy) type is very common. Insulation class: e.g., Class E resin. Primary current rating: as per application; vendor example supports up to high currents. Secondary current: commonly 1 A or 5 A.Accuracy: 0.2S, 0.2, 0.5S, 0.5 class CTs (depending on ratio) per spec. Short-time current rating: depending on design; e.g., some cubicle makers quote short-time current capability. Terminal construction: primary terminals heavily tinned copper, studs, etc. PTs (Potential / Voltage Transformers): Resin cast as well, often same insulation class. Primary voltage: e.g., 11 kV (or 11 kV/√3 depending on phase), depending on system. Secondary voltage: often 110 V or 110/√3 V (depends on spec). Accuracy class: 0.2, 0.5, 1.0 depending on application. Physical mounting: spec gives mounting dimensions (for example, for 11 kV, some spec says 280 × 190 mm for PT base mounting) Terminals: similar quality (tinned copper, studs) as CTs. Additional Information: Item Code: 8537 Production Capacity: CT ratio 25/5 A can measure up to ~475 kVA load at 11 kV. Delivery Time: according to the location Packaging Details: well packed with safety

Usage/Application Overhead Power Lines, Street Lighting, Traffic Signals, Communication Towers, And Other Structures Size 9m (L) Material Galvanized Iron Finishing Galvanized Shape Rectangular Incepted in the year 2020 Laxmi Treding Services is distinguished Wholesaler And Service Provider Offering an Enormous Consignment Of Electrical Transformer,Suspension Clamp,Flood Light,VCE Panel,VCB Panel,Earthing Electrode,Feeder Pillar Etc .
